Characteristic：
1. It is applicable to the transportation of light load articles, with a wide range of applications.
2. It can be applied separately or online, with flexibleapplication.
3. Low noise and stable transmission.
Technical parameters：
| Model | SGD401H | SGD401L | SGD401P |
| Processing length(mm) | 620-1850 | 620-2450 | 620-3200 |
| Processing width(mm) | 100-1250 | 100-1250 | 100-1250 |
| Processing thickness(mm) | 3-20 | 3-20 | 3-20 |
| Voltage | 380V/50HZ | 380V/50HZ | 380V/50HZ |
| Power(≈) | 0.75KW | 0.75KW | 0.75KW |
| Efficiency(m/min) | 10-80 | 10-80 | 10-80 |
| L * W * H(mm) | 2000*1400*900 | 3000*1400*900 | 4000*1400*900 |
| Weight(KG) | 300 | 450 | 600 |
