Characteristic：
1. Whole belt conveying, suitable for plates of various widths.
2. It can be connected or used separately, and the mode is flexible.
Technical parameters：
| Model | YSS24107P | YSS2L4107P | YSS34107P |
| Processing length(mm) | 620-1250 | 620-1550 | 620-1850 |
| Processing width(mm) | 100-630 | 100-630 | 100-630 |
| Processing thickness(mm) | 3-20 | 3-20 | 3-20 |
| Voltage | 380V/50HZ | 380V/50HZ | 380V/50HZ |
| Power(≈) | 4.5KW | 4.5KW | 4.5KW |
| Efficiency(m/min) | 10-80 | 10-80 | 10-80 |
| L * W * H(mm) | 4000*1600*1150 | 4000*1900*1150 | 4000*2200*1150 |
| Weight(KG) | 1200 | 1500 | 1800 |
